$ 239.99
SKU: DIY-EBE000016
Product Type: DIY Electric Bike

Brand new 26 Inch E-Bike Hub Motor Front Fat Tire Conversion Kit, added a charger and a battery bag to the kit, it is more convenient for you. 48v 1000 watts motor has an excellent efficiency that more than 80%, allows the speed up to 45 KM/H.

  • Powerful 1000W 48V brushless hub motor that allows up to 45 KM/H top speed
  • The kit includes motorized wheel(not inculdes the tire), motor controller, speed throttle, power break lever, wire harness,Pedal assist sensor
  • Thumb throttle with 3 LEDs indicator lights
  • New design of waterproof connection,more convenient and stable for Installing or maintaining
  • Motor specifications: 48v / 1000w / 470rpm
  • High motor efficiency: >80%
  • Motor diameter: 9.7 in (245mm)
  • Rim: width 3 1/4 in (8.3cm)
  • Tire: width 4 in (not inculdes the tire)
  • The motor dropout spacing is 135mm.
  • Brushless Front Hub Motor mounted 26 in fat tire single wall aluminum rim (rim width is 3 1/4 in)
  • Gross weight: 23.8 lbs (10.8KG)
  • Applicable Bike:Fat Tire Electric Bike(Not suit for other bike)
  • Applicable Tire:26"x4"
  • Hub size:22-1/2"
  • 1x Powerful 1000W 48V brushless hub motor
  • 1x 26" front wheel (the whole wheel without tire!)
  • 1x Electric controller
  • 2x Brake pullers
  • 1x Speed throttle
  • 2x handlebar grips
  • 1x PAS system
  • 1x Lead Acid Battery Charger
  • 1x Battery carrying bag
  • 1x Rope (color will pick at random)
  • 1set  Widing pipe/Cable tie
  • 1x Manual
    • Battery not included.
    • The charger only for lead-acid battery.
